Autophix ES610 Professional Auto OBD2 EOBD Diagnostic Tool for Volvo



Top 5 Reasons to Get Autophix ES610:

1. Quick access to Volvo all control systems problems, including engine, transmission, ABS, SRS, air conditioning, additional heater, etc.

2. Support Volvo Vehicle till 2014 year.

3. It can also works on all after 1996 OBD II compliant US, European and Asian vehicles.

4. Support special function like reset the service indicator.

5. It can display detail definition for the trouble codes.



Autophix ES610 Features & Functions:

1. Work on Volvo Coverages

The C30 2006-2008, The S40, 2004-2008, V40 (2004-2008)

V50 (2004-2008), S60 2001-2008, C70 2005-2008

V70 2001-2008

Exception: the Works of the mk2 models since the year 2000,

S80 2001-2006

Exception: also works on gas models, 1999-2000

Exception: also works with the D5252T MSA 15.8 system
1999-2000

XC70 2001-2008

XC90 2003-2008

Exception: The ES610 include OBDII /EOBD test function ,so

it also works with the engine system of VOLVO 2008-2014



2. Autophix ES610 Other Features

Works on all after 1996 OBD II compliant US, European and Asian vehicles.

Easily determines the cause of the "Check Engine Light ( MIL)".

Reads hard(memory)/pending(intermittent) and historic codes and show definitions.

Turns off Check Engine Light (MIL), clears codes and resets monitors

Reads live data-stream.

Views freeze frame data.

I/M monitor readiness test.

Displays live O2 sensor test data.

Retrieves vehicle information (VIN, CIN and CVN).

Supports ALL OBD II protocols: CAN, J1850 PWM, J1850 VPW, ISO9141 and KWP2000.



3. Autophix ES610 SPECIFICATION

Display: Backlit, 128 × 64 pixel display with contrast adjustment.

Operating Temperature: 0 to 80°C (32 to 176 F°).

Storage Temperature: -20 to 70°C (-4 to 158 F°).

External Power: 8.0 to 18.0 V power provided via vehicle battery.

Dimensions:125*70*22mm.



Package List:

1pc x Autophix ES610
